Patents

Mr. McKee’s U.S. Patents Include:

  • 5,254,823
    5,434,390
    5,558,793
    5,620,731
    5,927,265
    5,990,466

  • 6,008,483
    6,060,701
    6,140,626
    6,262,406
    6,486,453
    6,550,488

  • 6,580,360
    6,810,343
    6,821,354
    6,915,135
    7,104,269
    7,195,023

  • 7,332,041
    7,435,931
    7,919,737
    7,921,841
    8,022,341
    8,026,463

  • 8,129,665
    8,134,102
    8,733,236
    8,746,134
    8,759,731
    8,993,945

  • 9,161,547
    9,288,997
    9,326,639
    9,372,006
    9,480,364
    9,642,374

  • 9,677,774
    9,681,773
    9,723,951
    9,730,552
    9,775,358
    9,857,082

  • 9,874,358
    9,879,865
    9,974,312
    10,080,172
    10,080,173
    10,337,745

Modular 3-in-1 Appliance

Plexor Modular Cooking Apparatus
Patent Number 5,434,390

View Representative Patent

A modular cooking apparatus is disclosed. The modular cooking apparatus includes a housing having a first interchangeable cooking module, and a single power connection for receiving electrical power from a wall outlet. The first interchangeable cooking module contains a first oven, and the second interchangeable cooking module contains a second oven. The second oven is a different type from the first oven. The modular cooking apparatus also includes a controller within the housing for controlling the first and second ovens. The controller includes a memory for storing a list of food items to be cooked within the modular cooking apparatus and a corresponding oven type for each of the food items. The modular cooking apparatus further includes a control panel on the housing for displaying only the food items for winch the first oven or the second oven is a corresponding oven type.


Structured Air Technology®

Vector Multi-Cook Ovens
Patent Number 10,088,172B2

View Representative Patent

A jet plate for directing a flow of air into a cooking cavity of an oven may comprise a body configured to be disposed along a top wall or a bottom wall of the cooking cavity, and one or more structured air inlets that are openings through the body. Each of the structured air inlets comprises holes and slots that are alternatingly arranged and serially connected. The structured air inlets enable air to be introduced into the cooking cavity in a structured formation to improve cooking speed and cooking efficiency. In addition, structured air inlets in a jet plate may be configured in various manners to address unevenness in the distribution of airflow within the cooking cavity.


Precision Impingement®

Matchbox Oven
Patent Number 8,733,236

View Representative Patent

A matchbox oven is disclosed. The matchbox oven includes a housing, a slider, a mover and a heat source. The housing includes a cavity having a first and second openings. The mover moves the slider in and out of the cavity through the first and second openings. The heat source provides heat to the cavity for heating up any food item placed on a portion of the slider located within the cavity. The slider, which is configured to receive food items, includes multiple stoppers to serve as oven covers for preventing heat within the cavity from escaping through the first and second openings. When necessary, a portion of the slider can also be utilized as a heat sink for lowering the temperature of the cavity during oven operation.


Planar Plumes®

High-Speed Cooking Oven with Optimized Efficiency
Patent Number 8,022,341 B2

View Representative Patent

An improved oven is aimed at optimizing heat transfer and delivering an optimal cooking efficiency in comparison to conventional high-speed cooking ovens. The oven includes tubes that generate plume arrays of a heated gas and introduce them into a cooking chamber of the oven. The tubes may be removably located at the bottom of the cooking chamber of the oven. The tubes are dimensioned for hot air impingement to tighten impingement plume arrays, subject to the space constraints of the oven’s cooking chamber. With the optimized cooking efficiency provided by the present invention, high-speed cooking technology may now be extended to ovens operating on a power supply based on a voltage less than 220 volts, preferably between 110 and 125 volts, with more productive results, so that the high-speed cooking technology may find wider applicability and a broader customer base.


Ventless Cooking

Recycling Oven with Catalytic Converter
Patent Number 5,927,265

View Representative Patent

A recycling cooking oven providing a substantially closed environment, includes a thermal plenum for supplying a stream of hot air into a cooking chamber and for receiving a stream of hot air from the cooking chamber, the thermal plenum maintaining a reservoir of hot air therein. The cooking chamber of the oven supplies a stream of hot air into the thermal plenum and receives a stream of hot air from the thermal plenum, the cooking chamber cooking foods therein at least partially with a stream of hot air and such foods adding oxidizable components to the hot air of the stream. A blower and ducting cause the stream of hot air to circulate in substantially a continuous travel path including the thermal plenum and the cooking chamber. A catalytic converter is disposed in the travel path of the stream of hot air, downstream of the cooking chamber and upstream of the thermal plenum, for flamelessly oxidizing oxidizable components in the hot air of the stream leaving the cooking chamber, thereby both to remove them from the hot air of the stream and to release at least some additional heat energy into the hot air of the stream.


Rapid Cook with Controls

Quick Cooking Oven
Patent Number 5,434,390

View Representative Patent

An oven for cooking by hot air impingement includes a housing defining a cooking chamber adapted to receive a food product for cooking, a hot air plenum configured and dimensioned to hold a volume of air and a conduit for providing gaseous communication therebetween. Associated with the plenum is a thermal energy source for heating gas disposed in the plenum.
